Description:
High Efficiency Noiseless CE Spray Cleaning Machine Automatically
Machine features :
1. Automatic tooling and Fixtures cleaning machine, high pressure spraying cleaning machine
2. SUS 304 machine wash room and frame, resist Acid and Alkali corrosion, 10 years lifespan.
3. One-button easy operation, high pressure clean+ high pressure rinse+ compressed air dry, all process complete in one time automatically.
4. Closed-loop clean and rinse, clean solvent and rinse solvent is filtered in the machine.
5. Solvent recycled to use and cost down
6. The fixtures are clean and dry after cleaning, standby and ready for use.
7. Standard equipped with auto fill-in and drain-out function.
8. Labor cost save, clean efficiency raise
Machine Specs:
ItemModel Number
|
YS-5100
|
Clean Fixture size
|
Φ1000 x H 460mm as max
|
Spray system
|
All-round rotate spray clean and rinse
|
3Filter system
|
1mm/50um/20um filter
|
Clean tank capacity
|
80L
|
Rinse tank capacity
|
80L
|
Spray pressure
|
2~4kg
|
Air supply
|
0.5~0.7Mpa
|
Machine dimension
|
L2100 x W1550 x H 1600 (mm)
|
Machine weight
|
480kg
|
