Auto Stencil Cleaner , Domestic Pneumatic Steel Washing Machine Single Humane

Auto Stencil Cleaner , Domestic Pneumatic Steel Washing Machine Single Humane

product description:

YS-3110 pneumatic stencil cleaner is designed for solder paste and red glue printing stencil cleaning of SMT process. Driven by compressed air, constructed by super parts of pneumatic industry and our good manufacturing process, SME guarantee you an efficient ,reliable cleaning machine and high quality cleaning result. By “One button” easy operation, the machine complete “clean + dry “process automatically. Special designed pipe and patent rotation pod system guarantee stable jet pressure on stencil.

Product Details:

Place of Origin:	china
Brand Name:	YUSH
Certification:	CE
Model Number:	YS-750
Minimum Order Quantity:	1set
Packaging Details:	wooden packaging- L15500 x W1100 x H2150(mm)
Payment Terms:	T/T, L/C
Supply Ability:	100 month

Machine Feature:

1. SUS 304 structure, Acid and Alkali corrosion resistance, 10 years lifespan.

2. Totally Driven by compressed air , no electric power, no fire or explosion risk caused by electrical spark .

3. One button easy operation, clean and dry complete one time automatically

4. Special designed rotate rod and nozzle, ensure good cleaning quality and guarantee stable stencil tension

5. Equipped auto liquid fill in and drain function

6. Liquid recycle use to ensure low consumption

7. Inner-lock safety door, once open, machine stopped immediately to ensure operator safety

8. 3-level precise filtering system to make liquid clean by recycled use

9. Super well-known Pneumatic parts from all over the word ensure stable use of the machine


10. Modular design ensure easy maintenance



Machine SpecS:

Model Number	YS-750
Max stencil size	L1200 x W1200 x H40(mm)
Liquid tank	Max: 60L; Min28L
Clean time	2~6min
Dry time	3~8min
Air supply	0.5~0.7Mpa
Air consumption	200~1000L/min
Clean type	360°rotate jet clean + air dry
Filter system	20um/5um/1um(3 level)
Machine size	L15500 x W1100 x H2150(mm)
Machine weight	450KG
